Model

NWS-1261

Size(mm)

≤ 208x130x40mm

Pilot lamp

Power status indicator light, integrated with power button

Weight(kg)

≤ 1.0kg

Heat dissipation method

Passive cooling design without fans

Color

Space Grey

Overall Power Consumption

< 15W

Shell Material

aluminum alloy

Installation method

Compatible with embedded, wall mounted, and desktop versions

CPU

Elkhart Lake

Sky Lake

BIOS

AMI  BIOS

AMI  BIOS

Chipset

Intel® SOC

Intel® SOC

Pattern display

Intel® UHD Graphics

Intel® HD Graphics integrated graphics

network

6*Intel I226  Gigabit  network card

6*Intel I211AT

Memory

2*DDR4 3200MHz  Max 32G

2*DDR4 3200MHz  Max 32G

Hard disk

M Sata 128GB

M.2 2280 Sata 128GB

Function

Supports WiFi, Bluetooth, 4G, watchdog, diskless startup, network wake-up, and power on
Power on

Supports WiFi, Bluetooth, 4G, watchdog, diskless startup, network wake-up, and power on/off

Front I/O interface

1 * Power on button (LED)
1 * Reset button
1 * HDMI interface
1 * CMOS button
2 * USB2.0 interface
1 * COM interface using RJ45 interface
2 * USB3.0 interface
1 * Shift switch

1 * Power on button (LED)
1 * Reset button
1 * HDMI interface
2 * USB3.0 interface
1 * COM interface using RJ45 interface
2 * USB3.0 interface

Rear I/O interface

2 * LED PWR LED (green)+HDD LED (red)
6 * LAN interface
1 * DC IN interface
1 * M3 grounding screw hole
2 * Antenna

2 * LED PWR LED (green)+HDD LED (red)
6 * LAN port
1 * DC IN port
1 * M3 grounding screw hole
2 * Antenna

Power input

DC12V power supply

OS system

Support WIN10 / Linux

Certificate

CCC / CE / RoHs/FCC

National standard

parameter description

EMC

GB/T 9254.1-2021
Radio disturbance limits and measurement methods for information technology equipment

Radiation disturbance (B) level
Conducted disturbance (B) level

GB/T 17618-2015
Information technology equipment immunity limits and measurement methods

Meet the requirements of 6KV contact discharge and 12KV air discharge

Safety regulations

GB 4943.1-2011

Information technology equipment security - Part 1: General requirements

Grounding resistance: ≤ 0.1 Ω
Dielectric strength: Under a limited leakage current of 10mA, for Class I equipment, the withstand voltage of the primary circuit to the casing is ≥ 1.5KV AC or 2.2KV DC;
For Class II equipment, the withstand voltage of the primary circuit to the casing is ≥ 3.0KV AC or 4.3KV DC
Insulation resistance: ≥ 100M Ω
Leakage current: ground leakage current ≤ 3.5mA

Environment

GB/T 9813.4-2017
General specification for computers - Part 4: Industrial application microcomputers
GB/T 2423
environmental test

Working temperature: (-20) ℃~(60) ℃
Storage temperature: (-20) ℃~(70) ℃
Constant damp heat: (40) ℃ (95)% RH
Drop in packaging: The machine is packaged at a height of 1 meter, with 8 edges and 6 sides dropping once each
Vibration: 5-5.5Hz, displacement 25.4mm; 5.5~200Hz/acceleration 1.0g, working direction; Test duration 1 cycle
Impact: Half sine pulse, peak acceleration of 10g, pulse width of 11ms, and 3 times of impact in the working direction,
Noise: (0) dB

Model

Specification Description

notes

NWS-1261

Intel®J6412/DDR4 3200MHz 4GB/M-SATA 128GB

NWS-1261

Intel®Celeron®3855U/DDR4 2133MHz 8GB/M.2 2280 Sata 128GB
